Cudy 24-Port Unmanaged POE Switch – Rack Mount

R2 099,00

Key specs
PoE Standard
IEEE802.3af /IEEE802.3at
Max each port
15.4W ( IEEE 802.3af )
PoE compatibility
IEEE 802.3af/at adaptive
PoE port output
DC48-55V
Power Pin
Power over spare pairs 1/2(+) , 3/6 (-)
See all specifications ↓

16 in stock

SKU: FS1026PS1 Category: Brand:

Overview

The Cudy FS1026PS1 26-Port 10/100M PoE+ Switch with 1 FSP Slot allows you to manage your home or office network with ease. It features 24 Ethernet PoE ports with 2 uplink ports and 1 SFP slot. It's PoE RJ-45 connectors support any 10/100Mbps Ethernet devices, while the 2 non-PoE uplink ports support 10/100/1000Mbps Ethernet devices and it's compliant with IEEE 802.3af/802.3at network standards.

Used for many applications the Cudy FS1026PS1 works with IP Cameras for home, office or small businesses. It also works well with PCs, printers and access points in your home or office, making it ideal for small businesses. It even features a VLAN mode for additional security, this allows the ports to be isolated from one another.

Its simple plug and play interface makes it incredibly easy to use. Its sturdy design is made from high-quality metal. This gives you a longer service life and provides better heat dissipation, making it suitable for most environments. It also features a fanless design with venting holes to help dissipate heat with silent operation.

Watchdog guarantees the uninterrupted operation of your PoE devices. The PoE watchdog continuously monitors the connection status of remote hosts. If an error is detected on the remote PoE device, the PoE switch immediately restarts the device to bring it back to normal operation.

FEATURES:

  • 24 x 10/100M PoE+ ports
  • 2 x Gigabit Uplink port
  • 1 x 1.25Gbps SFP slot
  • 300 Watts PoE power budget
  • IEEE 802.3at / IEEE 802.3af standard compliant
  • Plug&play, simple setup with no configuration needed



Specifications

Connector Type24-Port 10/100M PoE+ Switch with 2 Gigabit Uplink Ports and 1 SFP Slot
Network Protocols
IEEE802.3
IEEE802.3u
IEEE802.3ab
IEEE802.3x
IEEE802.3z
PoE Parameters
PoE StandardIEEE802.3af /IEEE802.3at
Max each port15.4W ( IEEE 802.3af )
Max each port:30W ( IEEE 802.3at )
PoE compatibilityIEEE 802.3af/at adaptive
PoE port outputDC48-55V
Power PinPower over spare pairs 1/2(+) , 3/6 (-)
Network Media
10BASE-TCat 6 UTP(≤250 meters)
100BASE-TXCat5 or more UTP (≤100 meters)
1000BASE-TXCat5 or more UTP (≤100 meters)
Optical
Multi-Mode Fiber850nm, 1310nm
Transmission Distance550m/2Km
Single-Mode Fiber1310nm, 1550nm
Transmission Distance20/40/60/80/100/120km
Performance Specification
Bandwidth10.8Gbps
MAC Address2K
Packet Neck Scarfer Memory1M
Packet Forwarding Rate8Mpps
Forwarding ModeStore-And-Forward
Power Supply
Product Input VoltageAC100-240V 50/60Hz
Output52V5.76A, Power Budget: 300W
PWR - Power supply indicator(Red)
PWR - Power supply indicator(Red)PWR - Power supply indicator(Red)
LightingPowered
Un-LightNo Power
SW - DIP indicator(Green)
OFFNormal
VlanLighting
ExtendSlow flash
1-27 - RJ-45 ACT indicator(Green)
1-27 - RJ-45 ACT indicator(Green)1-27 - RJ-45 ACT indicator(Green)
LightingConnecting
FlashingData Transmit
Un-LightDisconnect
MTBF100,000 hours
Product Dimensions32 x 21 x 4.6 cm
Product Weight1900g
General
BrandCudy
Model / part numberFS1026PS1

What's in the box

  • Cudy FS1026PS1 26-Port 10/100M PoE+ Switch with 1 FSP Slot - Grey x1
  • Power Adapter x1
